Powerful Pipe Coupler

Powerful Pipe Coupler Powerful Pipe Coupler Powerful Pipe Coupler Powerful Pipe Coupler

Light and Heavy Duty Models. One man can properly join from 4"-12" pipe with this powerful tool.

shop ↓

805.237.9993

Powerful Pipe Coupler

Powerful Pipe Coupler Powerful Pipe Coupler Powerful Pipe Coupler Powerful Pipe Coupler

Light and Heavy Duty Models. One man can properly join from 4"-12" pipe with this powerful tool.

shop ↓

Site Content

Adjustable Clamp 6" to10"

Powerful & Fast Lever Drive

Adjustable Clamp 6" to10"


The PipeFitter™ does the work of many men and will pay for itself the first day you own it. One man can align pipe and fittings, glue, and prime both joining ends and in a matter of seconds powerfully complete manufacture recommended union. This is a MUST HAVE TOOL for anyone who works with 3" or larger diameter PVC pipe.



Don't start your next piping project without The PipeFitter™. Remember, the The PipeFitter™ is not available in stores, so order yours online today!
NOTE: versions for pipe-diameters of 4" to 8" are available now, 10" and 12" will be build on request only!

Interested in technical details? Pipefitter Standard or Pipefitter Heavy Duty
pipe

Announce coming events

Powerful & Fast Lever Drive

Adjustable Clamp 6" to10"

The powerful and versatile The PipeFitter™ precisely aligns the pipe and/or fitting and presses the pipe into the proper fitting insertion depth.


The PipeFitter™ maintains  alignment  during assembly, and holds cemented connections to prevent the fitting from backing-off until the initial set time is achieved.  Interested in technical details? Pipefitter Standard or Pipefitter Heavy Duty

Powerful & Fast Lever Drive

Powerful & Fast Lever Drive

Powerful & Fast Lever Drive

Typically, assembling 3" and larger diameter pipe requires at least two workers. One worker simultaneously holds both ends out of the dirt, glues, primes and aligns the ends for insertion while the other worker physically "pushes" the pipe into the fitting socket while the cemented surfaces are still wet.


 Unfortunately due to job site contaminates and pipe conditions (misshaped or deformed ends and close tolerances) the amount of force necessary to fully seat the connections is rarely accomplished. The end result is a weak and ineffective connection one that can leak and or separate during the backfill.


Medium Duty 3"-6"

Multiple Drive and Clamp Options

Powerful & Fast Lever Drive

Our Medium Duty tool is ideal for quickly joining 3" through 6" schedule 40/80 PVC pipe. Simply place the Ratchet Drive Clamp assembly on the joining pipes. Next, tighten the moveable clamp on the spigot end of the joining pipe and place & tighten the stationary clamp behind the bell housing of the adjoining pipe. Glue each end according to the manufacturer's recommendations and activate the ratchet drive to powerfully complete a fully inserted coupling.

Multiple Drive and Clamp Options

Multiple Drive and Clamp Options

Multiple Drive and Clamp Options

Check out the newly designed adjustable clamps.

Adjustable Lever Drive

Multiple Drive and Clamp Options

Multiple Drive and Clamp Options

With one motion you can powerfully join all sizes of pipe. The lever drive allows for proper insertion depth. The pipefitter join and disassembled pipe joints. Forward and Backwards motion provides accurate insertion depth.

Price List

Pipefitter Light/Medium Duty

Ideal for 3"-6" inch PVC Pipe.

Ratchet Drive Light/Medium Duty

$420.00

Ratchet Drive Rack

LD Pipe Clamps

$219.00

3"-4" Hand Twist Clamps

MD Universal Pipe Clamps

$420.00

Supports 3",4" & 6" Clamp shoe sets

Leg Support - Light/Medium Duty

$85.00

 Ground Clearance Legs

Glue Cups

89..00

Pint Size Glue Cups

4" Clamp Shoe (Set)

159.00

Designed for use with MD Universal Clamp Set

6" Clamp Shoe (Set)

169.00

Designed for use with MD Universal Clamp Set

Speed Handles

130.00

Significantly reduces tool connection time


Heavy Duty Tool

Designed for 4"-12" PVC & Series 900 PVC Pipe

Small Lever Drive

$720.00

4"-8" Lever Drive

Medium Lever Drive

$790.00

4"-8" Lever Drive

Large Lever Drive

$850.00

6"-12" Heavy Duty Lever Drive

4" Clamp Set (HD)

$325.00

4" Clamp Set

6" Clamp Set (HD)

$350.00

6" Clamp Set

8" Clamp Set (HD)

$425.00

8" Clamp Set

10" Clamp Set (HD)

$575.00

10" Clamp Set

12" Clamps Set (HD)

Call For Price

12" Clamp Set

The PipeFitter™ takes the worry and work out of joining 3”-12” PVC pipe and conduit.

The Pipefitter (Heavy Duty) for diameters 6"-12" Pipe



  • The PipeFitter™ provides 1 ton of precise mechanical pressing power to replace ineffective brute force (pry bars, hammers, backhoe assist and stabbing) to complete strong, tight and dependable joints.
  • The Pipefitter HD is specifically designed for the rigors of joining 6" to 12" CIOD C900 water and drainage pipes.

Description

 The Pipefitters™ design allows the operator to securely clamp both ends up out of the dirt to facilitate ease of lubricant application and to keep both clean of contaminates. Unlike current methods, The Pipefitter™ requires only one worker to align the bell coupling with the spigot end, lubricate and powerfully complete a manufacturers recommended union in a matter of seconds.

The Pipefitter™ provides 1 ton of precise mechanical pressing power to replace ineffective brute force (pry bars, hammers, backhoe assist and stabbing) to complete strong, tight and dependable joints. The Pipefitter™ securely holds the bell end while applying steady and constant force on the spigot eliminating the possibility of the spigot being jammed into the neck of the bell and over insertion of the previously completed joints in the line.

Highlights "The Pipefitter 6 - 12":

  • Powerful clamps up to 12” diameter
  • Produces over 1 ton of pulling power
  • Steel drive mechanism
  • Insures full Insertion Depth
  • Eliminates under insertion and pipe separation
  • Engineered for strength
  • Eliminates a 2nd worker
  • Large diameter PVC pipes are easily joined
  • Easy to transport and use
  • No plastic parts to break or wear out
  • Saves Time and Money

Specifications: Clamping Range:6”-12" DiameterMax. Clamping Force:1 metric tonJack Method:Manual Ra



.
